Draeger 6520260, Dräger MultiTest med. Int. (Impactor and tubes included) comprising of 1 O2 pressure regulator, measuring device for 7 tubes, impactor adapter, NIST connector, closing coupling, stopwatch, tube opener Dräger TO 7000, bubble test hose, instruction for use, transport case (blue).

Dräger MultiTest med. Int., with Dräger Tubes, Draeger 6520260

DrägerMultiTest med. Int.

Designed to meet the requirements of medical supply systems, the Dräger MultiTest med. Int. checks the purity of medical gases. A single test system is all that is needed to detect contaminants in compressed air, nitrous oxide, carbon dioxide and oxygen.

Dräger MultiTest med. Int. (Impactor and tubes included): comprising of: 1 - O₂ pressure regulator, measuring device for 7 tubes, impactor adapter, NIST connector, closing coupling, stopwatch, tube opener Dräger TO 7000, bubble test hose, instruction for use, transport case (blue)

MEETS THE REQUIREMENTS OF MEDICAL SUPPLY SYSTEMS

Designed to meet the requirements of medical supply systems, the Dräger MultiTest med. Int. checks the purity of medical gases. A single test system is all that is needed to detect contaminants in compressed air, nitrous oxide, carbon dioxide and oxygen.

Thanks to its versatility and ability to handle all medical gases, this compact and transportable test set represents a cost-effective and economical solution.

CERTIFIED DETECTION

Use of the Draeger MultiTest med. Int. guarantees a reliable check in accordance with USP (United States Pharmacopeia) quality requirements.

The Draeger MultiTest med. Int. is a member of the innovative Aerotest family of products which is based on the well known Draeger Tube® detection system, an efficient method of detecting and measuring toxic gases. The test system determines the concentrations of water vapour, carbon monoxide, carbon dioxide, hydrogen sulphide, nitrous gases, oil and other contaminants in the compressed air flow. The concentrations can be determined either individually or simultaneously.

QUICK AND EASY APPLICATION

The measuring device, which functions independently of a power source, is connected by means of a plug-in connector to the filling system or device cylinder to be checked. Adapters supplied with the MultiTest ensure that the system can be used internationally. In just five minutes, the Quick-Check guarantees a precise measurement result and provides information about the degree of contamination.

THE DRAEGER OIL IMPACTOR

The new Draeger Oil Impactor is specially designed to test compressed air for oil aerosols. For the first time, not only conventional oils but also synthetic oils - regardless of type and viscosity - can be measured easily and precisely.

ALWAYS READY FOR USE

The complete test set comes in a handy carrying case.

Technical Data

• Dimensions of carrying case (L x W x H) 400 x 300 x 91 mm (15.8 x 11.8 x 3.6 in).
• Weight, including contents approx. 3.0 kg (6.6 lbs).
• Max. supply pressure 20 bar (290 psi).
• Supply pressure (set on delivery) 3.0 bar.
• Connection for compressed air supply 9 mm barbed nipple.
• Flow rate 0.2 and 4.0 (l/min.)

Dräger MultiTest med. Int. Part Number 6520260 Includes the following Dräger-Tubes:

• 1 pack of 10 Dräger Oil Impactors, Part Number 81 035 60
• box of 10 Dräger-Tubes carbon dioxide (CO2) 100/a-P, Part Number 67 28 521.
• box of 10 Dräger-Tubes carbon monoxide (CO) 5/a-P, Part Number 67 28 511.
• box of 10 Dräger-Tubes nitrous gases (NOX) 0.2/a, Part Number 81 03 661.
• box of 10 Dräger-Tubes sulfur dioxide (SO2) 0.5/a, Part Number 67 28 491.
• box of 10 Dräger-Tubes hydrogen sulfide (H2S) 1/d, Part Number 81 01 831.
• box of 10 Dräger-Tubes water vapor (H2O) 20/a-P, Part Number 81 03 061.

Ordering Information

Dräger MultiTest med. Int. (Impactor and tubes not included), Part Number 6527319

Dräger MultiTest med. Int. (Impactor and tubes not included): comprising of: 1 - O₂ pressure regulator, measuring device for 7 tubes, impactor adapter, NIST connector, closing coupling, stopwatch, tube opener Dräger TO 7000, bubble test hose, instruction for use, transport case (blue).

Dräger MultiTest med. Int. with Dräger-Tubes, Part Number 6520260

Dräger MultiTest med. Int. (Impactor and tubes included): comprising of: 1 - O₂ pressure regulator, measuring device for 7 tubes, impactor adapter, NIST connector, closing coupling, stopwatch, tube opener Dräger TO 7000, bubble test hose, instruction for use, transport case (blue)

Including: 1 pack of 10 Dräger Oil Impactors, Part Number 8103560
1 box of 10 Dräger-Tubes carbon dioxide (CO2) 100/a-P, Part Number 67 28 521
1 box of 10 Dräger-Tubes carbon monoxide (CO) 5/a-P, Part Number 67 28 511
1 box of 10 Dräger-Tubes nitrous gases (NOX) 0.2/a, Part Number 81 03 661
1 box of 10 Dräger-Tubes sulfur dioxide (SO2) 0.5/a, Part Number 67 28 491
1 box of 10 Dräger-Tubes hydrogen sulfide (H2S) 1/d, Part Number 81 01 831
1 box of 10 Dräger-Tubes water vapor (H2O) 20/a-P, Part Number 81 03 061

HAZMAT Item: No

Minimum Order Quantity: 1

New: YES

Quantity per Standard Package: 1

Type: 6520260, Dräger MultiTest med. Int., complete

Unit of Measure: EA
