Description

Features & Notes

Requires FR valve priced separately

Model 3060FR, freeze-resistant, wire reinforced round concrete pedestal drinking fountain with exposed aggregate finish.

Freeze-Resistant Concrete Pedestal Fountain

The Haws® Model 3060FR, freeze-resistant, wire reinforced round concrete pedestal drinking fountain with exposed aggregate finish.

Concrete with exposed aggregate finish and wire to reinforce the casting offers an extremely solid and highly protected fountain.
Hood extension protects the bubbler head with a partial enclosure, for a greater protected drinking point.
Simplistic Portland Gray cement creates just the right amount of appeal for an outdoor fountain.

Specifications

Model 3060FR freeze-resistant circular concrete pedestal drinking fountain shall include a polished stainless steel basin, polished chrome-plated push-button, polished chrome-plated brass vandal-resistant bubbler head protected by a hood extension, polished chrome-plated brass vandal-resistant waste strainer, Portland Gray exposed aggregate concrete finish with wire reinforcement, integral mounting feet, vandal-resistant stainless steel access plate, and 1-1/4" O.D. tailpiece. REQUIRES MODEL 6518FR PRICED SEPARATELY.

Bottle Filler Flow Rate (GPM): N/A

Bubbler Flow Rate (GPM): .45 GPM

Country of Origin: US

HAZMAT Item: No

Item Height: 43.00

Item Length: 12.00

Item Weight: 198.00

Item Width: 12.00

New: NEW

Other Flow Rate (GPM): N/A

Type: Freeze-Resistant Concrete Pedestal Fountain

Unit of Measure: EA
