Haws 7433FP, Freeze Protected Wall Mount Eyewash

Model 7433FP, wall-mounted, freeze protected eyewash with Soft-Flo heads.

Freeze Protected Wall Mount Eyewash

Haws® Model 7433FP, wall-mounted, freeze protected eyewash with Soft-Flo heads.

• A great addition to multiple unsafe environments where the eyes may be exposed to corrosive materials.
• Easily detected and maintained, emergency equipment is equipped with safety sign and test card to record weekly testing.
• Reducing installation time, eyewash and valve assembly is pre-built and fully water/pressure tested.
• Fully functional in freezing environments when installed properly.
• Certified by CSA to meet the ANSI Z358.1 Standard for Emergency Eyewash and Shower Equipment.

Specifications

Model 7433FP freeze protected wall-mounted eyewash shall include a stainless steel 11" (27.9 cm) round bowl, stainless steel eyewash yoke assembly with Soft-Flo ABS plastic eyewash anti-surge heads with integral flow controls and dust covers, self-draining valve, and brass stay-open ball valve equipped with stainless steel ball and stem, and stem extension. Unit to be used with a maximum wall thickness of 12" (30.5 cm) and shall include chromate protective cast-aluminum wall bracket, universal sign, 1/2" NPT inlet, and 1-1/4" NPT outlet.

Country of Origin: US

Eyewash or Eye/Face Wash Flow Rate (GPM): 2.4 GPM

HAZMAT Item: No

Item Height: 15.00

Item Length: 30.00

Item Weight: 11.00

Item Width: 15.00

New: NEW

Other Flow Rate (GPM): N/A

Shower Flow Rate (GPM): N/A

Type: Freeze Protected Wall Mount Eyewash

Unit of Measure: EA

UPC Code: 611970346434
